Sabre G300 Heavy duty concrete floor grinder is the ideal machine for general grinding and finishing of concrete floors and similar, also perfect for removing coatings and adhesives – all can be achieved totally dust free! We have designed and built the Sabre G300 to deliver trouble free performance for many years with an absolute minimum of service or maintenance work. It is built withstand the rigours of site use (and abuse) and is really simple to operate and maintain. With a grinding head weight of over 47kg and a three phase, 4kW motor it offers exceptional performance.
The standard grinding head is 300mm in diam and has 12 diamond segments fitted (Six bolt on plates). Sabre G250 110V and 240V versions are available, they are fitted with 250mm diam. grinding heads and have ten diamond segments fitted (Five bolt on plates). The unique design of the rear axles and wheels ensures the machine can always be set to grind level and flat to the floor for the best possible results and performance.
The Sabre machines are fitted with our own design of flexible drive coupling, the “G” coupling, which has repeatedly proven to be far more durable than alternatives fitted by our competitors. As a result levels of vibration are reduced and more of the power and torque generated by the electric motor is actually delivered to the grinding head making the Sabre a genuinely very aggressive machine. The “G” coupling also ensures even wear of the diamond segments during use, no more throwing away expensive grinding discs that have completely worn away on one side of the disc only!
The chassis is fabricated in heavy gauge steel and welded throughout to ensure a robust durable machine. The on/off switch has a metal protective guard and to facilitate easy loading a grab handle is welded onto the front housing. Dust control is completely effective using 50mm vacuum hose. The heavy duty rubber dust skirt can be adjusted for wear and is both simple yet fully effective.
The Sabre G300 has long been a stalwart of our hire fleet were it has proven to be totally reliable. Breakdowns are unheard of and often a hire turns into a sale as customers are converted to the simple strengths and outstanding performance and reliability of this UK manufactured machine.
A comprehensive range of diamonds are available to fit the Sabre G300 ranging from aggressive pcd plates for latex removal through to the finer grits that are ideal for finishing concrete floors.
A special build version of the Sabre G300 is available for use with our range of bush hammer heads. Normally this version is available from stock fitted with a three phase, 400V motor. A single phase, 240v version can be supplied to order, please contact our technical desk for further information.
The Sabre G300 / G250 concrete floor grinders are available for hire, for further details please call us on (01405) 862688. Ask about our hire before buying service
